Single tank series
Multi-Capacity /45L-1500L Industrial Standard Single Tank ultrasonic Cleaner with Heating
The Single Tank Ultrasonic Cleaner Series is available in flexible capacities from 45 liters to 1500 liters. Other capacity can be customized. All items under this series come standard with heating function and digital timer. From small, precision parts to large, heavy-duty components, suitable machines are available.
Core Advantages & Features
Available in a wide range of capacities from 45L to 1500L, this stander single tank ultrasonic cleaner series is designed for versatile industrial cleaning tasks — from small precision parts to large heavy-duty components. All models come standard with heating function and digital timer.
Key Features
- Adjustable Ultrasonic Power: 0 - 10800W (adjustable according to inner tank size)
- Heating Temperature: Up to 95°C, can meet cleaning solvent requirement.
- Digital Timer: For precise control of cleaning cycles
Powerful Cleaning Performance
The adjustable ultrasonic power (0-10800W) allows flexible control of cavitation intensity, while the heating system raises the solution temperature up to 95°C to significantly enhance cleaning efficiency. This combination effectively removes oil, grease, dust, rust, carbon deposits, and fine particles from complex surfaces, blind holes, and intricate workpieces, delivering superior and consistent results.
Durable Construction
- Hand-welded tank, double sides welding at four corners of the tank, resistance to wear and long work life.
- With stainless steel & sound-insulated lid and multi-direction castor, can move the ultrasonic cleaning machines easily. With stainless steel SUS304 basket, ensure better loading and protect the parts, then ensure throughly wave penetration.
- Industrial transducer, ensure cleaning of every corner and longer durability
Customization Available
We offer full customization services and cleaning solutions.
Including tank capacities, ultrasonic power, heating power, filtration system, and additional functions such as spraying, automatic lifting, bubbling, cooling, agitation, etc., to meet your specific project requirements.
Customer Benefits
This ultrasonic cleaner series helps improve cleaning quality and efficiency, reduce manual labor and parts damage, lower operational costs, and achieve more environmentally friendly green cleaning.
Technical Data & Specifications
Product Item NO. | Inner Tank Size (mm) | Capacity (L) | Inner Tank Material (T2.0) | Ultrasonic Transducer | Ultrasonic Power (Adjustable) | Ultrasonic Frequency (Optional) | Time Control | Heating Power | Cleaning Temperature Control | Power Supply |
|---|---|---|---|---|---|---|---|---|---|---|
SNXS-1012S | 500*300*300 | 45 | SUS304 | 12 Pcs | 0-600W | 28/40KHz | 1-99MIN | 1.5KW | Normal Temperature - 95℃ | Single-Phase 220V |
SNXS-1018S | 500*350*350 | 61 | SUS304 | 18 Pcs | 0-900W | 28/40KHz | 1-99MIN | 1.5KW | Normal Temperature - 95℃ | Single-Phase 220V |
SNXS-1024S | 550*400*400 | 88 | SUS304 | 24 Pcs | 0-1200W | 28/40KHz | 1-99MIN | 3KW | Normal Temperature - 95℃ | Single-Phase 220V |
SNXS-1030S | 600*450*400 | 108 | SUS304 | 30 Pcs | 0-1500W | 28/40KHz | 1-99MIN | 3KW | Normal Temperature - 95℃ | Single-Phase 220V |
SNXS-1036S | 600*500*450 | 135 | SUS304 | 36 Pcs | 0-1800W | 28/40KHz | 1-99MIN | 4.5KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1048S | 700*500*500 | 175 | SUS304 | 48 Pcs | 0-2400W | 28/40KHz | 1-99MIN | 6KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1060S | 800*600*550 | 264 | SUS304 | 60 Pcs | 0-3000W | 28/40KHz | 1-99MIN | 6KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1072S | 1000*600*600 | 360 | SUS304 | 72 Pcs | 0-3600W | 28/40KHz | 1-99MIN | 9KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1084S | 1200*700*500 | 420 | SUS304 | 84 Pcs | 0-4200W | 28/40KHz | 1-99MIN | 9KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1090S | 1200*800*500 | 480 | SUS304 | 90 Pcs | 0-4500W | 28/40KHz | 1-99MIN | 9KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1096S | 1200*800*600 | 560 | SUS304 | 96 Pcs | 0-4800W | 28/40KHz | 1-99MIN | 18KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1108S | 1000*900*600 | 540 | SUS304 | 108 Pcs | 0-5400W | 28/40KHz | 1-99MIN | 18KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1120S | 1000*800*800 | 640 | SUS304 | 120 Pcs | 0-6000W | 28/40KHz | 1-99MIN | 18KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1132S | 1000*1000*800 | 800 | SUS304 | 132 Pcs | 0-6600W | 28/40KHz | 1-99MIN | 18KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1144S | 1200*1000*800 | 960 | SUS304 | 144 Pcs | 0-7200W | 28/40KHz | 1-99MIN | 24KW | Normal Temperature - 95℃ | Three-Phase 380V |
SNXS-1216S | 1500*1000*1000 | 1500 | SUS304 | 216 Pcs | 0-10800W | 28/40KHz | 1-99MIN | 36KW | Normal Temperature - 95℃ | Three-Phase 380V |
Why You Need an Ultrasonic Cleaner?
The Limitation of Traditional Cleaning
Common cleaning challenges solved by our technology:
- Inaccessible Internal Channels: Dirt trapped in deep blind holes and cooling jackets that manual tools can't reach.
- Risk of Surface Damage: Traditional abrasive cleaning ruins precision tolerances or delicate surface finishes.
- Manual Cleaning Inefficiency: High labor costs and inconsistent results from repetitive manual washing.
- Some stains are difficult to remove: such as years of carbon buildup and heavy oil stains.
Performance Comparison Table:
Comparison Item | Traditional Cleaning (Manual/Soaking) | Ultrasonic Cleaning | Advantages of Ultrasonic |
|---|---|---|---|
Cleaning Time | 30–60 mins or longer | 5–15 mins | Reduces time by 60%–85% |
Contaminant Removal | Low (Blind holes & gaps remain dirty) | Extremely High (99%+) | Significantly cleaner & better consistency |
Microbial Reduction | Low (typically 20%–60%) | Up to 99.9% | Dramatic 98%+ reduction |
Chemical Usage | High (Strong solvents needed) | Low (Mechanical force) | Reduces chemical cost by up to 80% |
Water Consumption | High (Repeated rinsing) | Low (Recyclable solution) | Reduces water usage by 70%+ |
Labor Intensity | High (Heavy manual work) | Low (Automated process) | Drastically reduces human error & labor |
Consistency | Variable (Depends on operator) | Highly Consistent | Stable, reliable results every time |
How Ultrasonic Cavitation Works?
- Generation: High-performance transducers create 40kHz ultrasonic waves.
- Cavitation: Millions of microscopic bubbles form and penetrate deep into crevices.
- Implosion: Bubbles collapse to release energy, scrubbing away dirt from blind holes instantly.
Application Areas & Cleaning Effect
Main Application Fields:
- Vehicle Industry: Engine Blocks, Fuel Injectors, Tires, Car Parts, DPF.
- Aerospace Industry: Turbine Blades, Precision Machinery Parts.
- Electronics Manufacturing: PCB Boards, Electronic Components, SMT Molds.
- Machinery Industry: Gear Parts, Metal Valves, Diesel Injectors.
- CNC Industry: Precision CNC Machining Parts, Tooling.
- Motorcycle Industry: Engine Components, Carburetors, Gears.
- Heavy Industry: Automotive workshops, Mold cleaning, Factory lines.
Logistics & Support
Shipping & Packing:
- Packing Details: 1 unit per wooden case with a protective wooden frame and stretch film.
- Delivery Lead Time: Standard industrial models typically ship within 15–25 days.
Order & Business Terms:
- Payment Terms: 30% deposit before production, balance before shipment.
- Minimum Order Quantity (MOQ): For industrial ultrasonic cleaning machine, 1 unit
- After-sales Support: Lifetime technical support and 1-year product warranty.
FAQ
Q: If I have not ever imported from China, how can i buy from you?
A: We will supply the Ultrasonic cleaning machine and ask the freight forward agent to in charge of the delivery. No matter what kind of trade terms, we can support you, such as EXW, FOB, CIF. Especially with DDP trade term, you don’t need to worry about customs clearance or logistics.
